Description This RJ45 plug by Delock can be used to connect network cables. The connector offers quick and easy assembly and ensures secure cable contact.
With cable plug housing and protective cap
The housing can be used in switch cabinets or distribution boxes for feeding through network cables. The protective cap protects the plug from damage and dirt.
IP66 dust and waterproof
In combination with the Delock feed-through couplers 67061 and 67062 the housing offers increased protection against moisture, damage and dirt for outdoor cable connection.
Specification • Connectors:
1 x RJ45 plug
1 x LSA
• Cat.6A specification
• Built-in hole Ø: 25 mm
• Shielded
• Protection class: IP66
• TIA-568A/TIA-568B/industrial pinout
• For solid or stranded wire (27 - 22 AWG)
• For cable diameter from 5.5 - 7.5 mm
• Material: zinc diecast / plastic
• Dimensions (LxD): ca. 67 x 25 mm
Package content • RJ45 plug
• Cable plug housing
• Rubber seal
• Screw fitting
• Cable manager
• Protective cap
• Zip-tie
