- H.265+/H.265/H.264+/H.264 video compression
- Up to 60 Mbps incoming bandwidth, and 60 Mbps outgoing bandwidth
- Up to 8-ch network camera inputs
- Up to 4-ch 1080p decoding capability
Model HWN-2108H Video and Audio IP Video Input 8-ch Up to 4 MP resolution Incoming bandwith 60 Mbps Outgoing bandwith 60 Mbps HDMI Output 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA output 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz Video output mode HDMI/VGA simultaneous output
Decoding Decoding Format H.265+/H.265/H.264+/H.264 Recording resolution 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF Synchronous playback 8-ch Capability 4-ch @ 1080P (25fps) / 1-ch @ 4MP (25fps) Stream type Video, Video&Audio
Auxilliary interface SATA 1 SATA interface Capacity Up to 6TB capacity for each disk Alarm in/out N/A USB interface Rear panel: 2 × USB 2.0
Network Remote connection 16 Network protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP Network Interface 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
General Power supply 12 VDC Consumption (without HDD) ≤ 18 W Working temperature -10 to +55º C Working humidity 10 % to 90 % Dimensions 200 × 200 × 48 mm Weight (without hard disk) ≤ 1 kg
Certification FCC Part 15 Subpart B, ANSI C63.4-2014 CE EN50130-4, EN 61000-3-2, EN 61000-3-3
